Newmar 115-12-35CD Power Supply - Reliable Power for Your Marine Needs

The Newmar 115-12-35CD Power Supply by Newmar delivers unparalleled reliability for powering 12-volt communication and navigation equipment onboard commercial vessels. This super-rugged DC power supply is designed specifically for maritime environments where performance and durability are paramount.

Featuring:

• Exceptional Regulation: Ensures consistent voltage output for sensitive equipment, reducing the risk of damage and improving operational reliability.
• Noise-Free Output: The proven linear circuit design delivers a pure, noise-free power supply, vital for communication and navigation accuracy.
• Durable Construction: Built to withstand harsh marine conditions, this power supply promises a long service life, making it a smart investment for any vessel.

Perfect for commercial vessels navigating challenging waters or marine professionals requiring dependable power for communication and navigation equipment, the Newmar 115-12-35CD is your go-to solution. Backed by Newmar's commitment to quality, this power supply is built to exceed expectations and ensure safe voyages.

Don't compromise on reliability—experience the difference with the Newmar 115-12-35CD Power Supply!

115-12-35CD Power Supply

This super-rugged DC power supply is ideal for powering 12-volt communication and navigation equipment onboard commercial vessels where reliability is essential. The proven linear circuit design provides pure noise-free output and a long service life.

Features:

• Excellent Regulation and Ripple Spec (output voltage maintained within 1% under all rated line and load conditions)
• Polyurethane conformal coated PC board and corrosion-resistant heavy-duty aluminum case with integral shock mounts assure survival in hostile environments
• The heat generated by semi-conductors is extracted and dissipated by large heat sink fins for cool operation
• Protection: overvoltage, current limit; (set @ 105% of intermittent rating), thermal overload, and input/output fusing
• Thermally activated cooling fan on “CD” units

Specifications:

• Nominal Input/VAC: 115/230
• Maximum Input Current @115: 7.5
• Maximum Input Current @230: 3.5
• Output Amperage (Intermittent): 35
• Output Amperage (Continuous): 35
• Weight: 32 lbs. / 14.6 kg

Case Size:

• H x W x D (inch): 6.5” x 9.5” x 14.0”

Input Range

105-125/210-250 VAC (selectable), 50-60 Hz; Derate to 50% output below 110 and 220 VAC

Operating Temperature

C.D. Units - 0-65 degrees C, Derate linearly from 100% @ 50 degrees C to 50% @ 65 degrees C thermal Shutdown @ 85 degrees C case temperature

Duty Cycle:

• Intermittent: 20 minutes max on time, 20% duty
• Continuous: 24 hours/day 100% Duty

Options:

• Modify for use as a battery charger
• The output voltage is adjusted (see Output Voltage for range)
• Transfer relay for back-up battery in event of power failure (ERC option)

Output Voltage:

• 13.6 VDC (internally adjustable 12.6-14.5 VDC)
• Ripple: 40mV P-P (@ 110-125 / 220-250 VAC input)
• 1% Line and Load (@ 110-125 / 220-250 VAC input)

Mechanical:

• Powder-coated aluminum heat sink case
• Front panel terminal block
• Heavy-duty mounting flange
• Conformal-coated PC board
