Jabsco Par-Max HD3 Heavy Duty Water Pressure Pump - 12V - 3 GPM - 40 PSI

Jabsco Par-Max HD3 Heavy Duty Water Pressure Pump by Jabsco offers exceptional performance and durability tailored for maritime and RV applications. Designed to deliver reliable water pressure, this pump operates at 3 GPM and 40 PSI, making it a perfect choice for vessels with multiple water outlets.

Key Features:

• Co-molded Diaphragm Technology: Ensures long life and durability, even under high pressure.
• Heavy-Duty Motor: Features a robust design with cast aluminum lower housing for maximum performance.
• Self-Priming Capability: Allows for versatile installation with a dry self-priming capacity of up to 7 feet.

Ideal for boaters and RV enthusiasts seeking dependable water pressure, this product is supported by extensive certifications (CE, ISO8846) and a stringent quality assurance process, ensuring satisfaction and reliability.

Par-Max HD3 Heavy Duty Water Pressure Pump - 12V - 3 GPM - 40 PSI

HD (Heavy Duty) models include a wider diameter motor with a powder coated shell, cast aluminum endbells and lower housing to improve pressure capability and life. Available in configurations up to 6 GPM (23 LPM) and 60 PSI (4.1 BAR), these pumps deliver exceptional performance.

Standard models provide good performance in an economical footprint. These configurations are available in 1-3 GPM, perfect for vessels with 1-3 outlets. A plastic housing protects the motors on these units from corrosion.

Features:

• Co-molded diaphragm technology for long life and durability
• HD models feature heavy duty, motors and cast aluminum lower housings which allow for longlife, even at high pressures
• Efficient and quiet operation
• Integrated, sealed pressure switch for on-demand operation
• Self-priming allows for installation versatility
• Can run dry without damage
• Quick connect ports for ease of installation, servicing, and maintenance
• Vibration dampening mounting feet
• Equipped with integrated bypass module to reduce cycling and provide smoother flow

Specifications:

• Motor design: Brushed, permanent magnet TENV
• Pumphead upper housing material: Glass fiber reinforced polypropylene
• Diaphragm: Co-molded TPV
• Check valves: EPDM
• Max inlet pressure: 30 PSI (2.1 Bar)
• Fluid temperature range: 32°F – 140°F (0°C – 60°C)
• Dry self-priming capability: 7ft min (2.13m/min)
• Certifications: CE, ISO8846, RCM
• Ingress Protection: IPX6
