Blue Sea 7041 187 - Series Thermal Circuit Breaker - 70Amp
Blue Sea 7041 187 - Series Thermal Circuit Breaker offers superior circuit protection tailored for marine and automotive applications. This 70 Amp Circuit Breaker is designed to ensure safety and reliability in high-demand environments, making it ideal for installations aboard gasoline-powered boats.
Key Features:
- Integrated Switching and Protection: Combines both functions into a single device for seamless operation.
- Robust Construction: Made from thermoset polyester, ensuring durability and resistance to harsh conditions.
- Trip Free Design: Cannot be held "ON" during fault conditions, enhancing safety during critical moments.
Ideal for marine applications, this thermal circuit breaker is ignition protected and meets SAE J1171 external ignition protection requirements. It features waterproof recessed mounting holes for a clean appearance and large clearance around terminal studs for heavy gauge wire lugs.
With a maximum interrupt rating of 5,000 Amperes at 12 Volts DC, this circuit breaker guarantees quality and satisfaction in demanding situations. Choose the Blue Sea 7041 for unmatched performance and peace of mind.
187 - Series Thermal Circuit Breakers - Panel Mount70 Amp Circuit Breaker
PN: 7041
Features:
- Combines switching and circuit protection into a single device
- All components meet SAE J1171 external ignition protection requirements
- Clear, single lever operation
- "Trip Free" design cannot be held "ON" during fault current condition
- Waterproof
- Recessed mounting holes for clean appearance
- Self-trimming case eliminates the need for mounting panels or trim bezels
- Round case permits easy installation with standard sized hole saw
- Large clearance around terminal studs accept heavy gauge wire lugs
- Robust 5/16 terminals provide high torque connections
- Large lever with vertical/horizontal orientation provides indication of trip status
- Ignition protected - safe for installation aboard gasoline powered boats
| Specifications | |
| Circuit Breaker Class: | Type III - Switchable / Manual Reset - Trip Free |
| Type: | Thermally Responsive Bi-Metal Blade |
| Case Material: | Thermoset Polyester |
| Voltage Rating: | 48 Volts DC Maximum |
| Interrupt Rating: | 5,000 Amperes @12 Volts DC |
| 3,000 Amperes @24 Volts DC | |
| 1,500 Amperes @42 Volts DC | |
| Operating Temperature Range: | -25C° to +82C° |
