ARCO Marine Zeus 24V 7kW J180 4 Inch Alternator with Isolated Ground

The ARCO Marine Zeus 24V 7kW J180 Alternator is engineered for performance, delivering an unbeatable power output for your marine engine. With an impressive design, this alternator is a prime example of advanced engineering in the Alternators category. It generates an exceptional high amperage, making it the perfect choice for those who demand reliability and efficiency on the water.

Experience the power of continuous output with over 3kW (109 Amps) at just under 3,000 alternator RPM, and an astounding nearly 6kW (218 Amps) at under 6,000 RPM. This capability ensures that your vessel will have the power it needs, whether you’re cruising or running high-demand electronics.

• High Amperage Output: Consistently generates high amperage, crucial for extensive power requirements.
• Isolated Ground Design: Reduces electrical interference, enhancing performance and reliability.
• Robust Construction: Designed for marine environments, ensuring durability and longevity.
• Efficient Performance: Optimized for both cruising and high RPM usage, delivering power when you need it most.

What sets the Zeus 24V Alternator apart from typical alternators is its combination of high power output and isolated ground technology, allowing it to run efficiently under demanding conditions. This makes it an essential component for any serious boat enthusiast looking to upgrade their Engine Parts & Service.

Upgrade your marine electrical system with the ARCO Marine Zeus 24V 7kW Alternator and experience unparalleled performance at sea. Don't settle for less; ensure your boat runs smoothly and efficiently with this high-capacity alternator.

Order now to equip your vessel with the power it deserves!

Zeus 24V 7kW J180 4" Alternator with Isolated Ground

The ARCO Zeus 24v 7kW alternator generates extremely high amperage at cruising and higher RPMs. This alternator continuously generates over 3kW (109 Amps) at just under 3,000 alternator RPM and almost 6kW (218 Amps) at under 6,000 RPM. In real-world terms, a marine diesel engine at 1,500 RPM with a 2:1 pulley ratio generates over 3kW, and a Mercedes Sprinter at 1,800 RPM with a 3.21:1 ratio generates over 6kW!

The ARCO Zeus 24v 7kW alternator turns on for cruising or at mid to higher RPMs, runs cooler, and provides more power than older designs that are larger and heavier. The newest generation of 24V performance has arrived.

Competitor’s 24V alternators utilize a 12V rotor and field current which is less efficient and limits output at all RPMs. ARCO utilizes a native 24V rotor and field current. This results in our 24V alternator running cooler than competitor’s 24V alternators, having a direct impact onthe  alternator lifespan.

Features:

• Engineered for high energy production.
• Suitable for marine, RV, military, and commercial applications.
• Rapidly charges large battery banks.
• Coolest operating temperatures for increased performance:
• Heat shedding coatings
• Rectifier located on housing exterior
• Dual cooling fans
• OEM components
• Optimized for performance at idle speeds.
• Reduces the need for a generator by creating additional power with your engine.
• Unleash peak performance with E-Coat/Cerakote, keeping the high amp alternator cooler for sustained amperage output.
• Use the ARCO Zeus Bluetooth Alternator Regulator for maximum performance or lithium battery charging.
• SAE J1171 Certified.
• Proudly made in the U.S.A.

Technical Specifications:

• Voltage - 24v
• Field Type - P
• Rotor Poles - 16
• Stator Size - 138mm
• Frame Size - Large
• Weight - 15.89lbs/7.2kg
• Regulation - External Only
• Finish - (Black) E-coating
• Cut-In RPM - 1,962 Alternator RPM
• Maximum Alt RPM - 19,000
• Battery Post - M8 Thread Post, Side Mount
• Standard Pulley - 49K6 (6-groove, 49mm)
• Pulley Mount - 17mm diameter shaft, 25mm long, threaded M17 x 1.5
• Pulley Hardware - M17 x 1.5 x 24mm nut, w/ 18mm ID x 29mm OD washer (Included)
• Diodes - 6 positive, 6 negative, 80A Rated, Avalanche
• Max Output (Cold, 9,000 RPM) at 27.5v - 284 Amps - 7,810 Watts – 11.2 kW PTO
• Sustained Cruising Output (Hot, 6,000 RPM) at 27.5v - 220 Amps - 6,050 Watts – 8.6kW PTO
• Sustained Idle Output (Hot, 3,000 RPM) at 27.5v - 50 Amps 1,375 Watts – 2kW PTO
• Max Continuous Operating Temperature - 100°C / 212°F

Mounting Application:

• Replaces most Volvo Penta alternators using a 4” J180 saddle-style mount. Also, used on many larger industrial-based engines.
